• IC-601
    Voltage 1PH /110V or 220V 50Hz / 60Hz
    Power 0.37kw
    Pump Capacity 6m3 / hr(0.5HP) BUSCH
    machine size 520 x 430 x 510H(mm)
    Vacuum Chamber 340 x 330 x 120H(mm)
    sealing bar length 310mm x 1
    NW / GW 58kg / 72kg
    machine material #304 stainless
    Case Size(L*W*H) 580*500*750mm (0.22CBM)
  • IC-601-20
    Voltage single phase110V
    Power
    Pump Capacity 6m3/hr (0.5HP) BUSCH
    machine size 760 x 430 x 510H(mm)
    Vacuum Chamber 540 x 330 x 120H(mm)
    sealing bar length 310mm x 2 sealing bars Each of the front and back
    NW / GW 68kg
    machine material #304 stainless
    Case Size(L*W*H)
  • IC-611
    Voltage 1PH/110Vor220V 50Hz/60Hz
    Power 0.37kw
    Pump Capacity 6m3/hr (0.5HP)BUSCH
    machine size 580 x 430 x 550H (mm)
    Vacuum Chamber 410 x 330 x 160H (mm)
    sealing bar length 310mm x 1
    NW / GW 62kg / 79kg
    machine material #304 stainless
    Case Size(L*W*H) 500 x 680 x 660(mm)
  • IC-602
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr(1 HP)BUSCH
    machine size 680 x 550 x 540H(mm)
    Vacuum Chamber 480 x 450 x 140H(mm)
    sealing bar length (1)420mm x 1
    (2)420mm x 2
    NW / GW 90kg / 110kg
    machine material #304 stainless
    Case Size(L*W*H) 780 x 650 x 790(mm)
  • IC-612
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr(1HP)BUSCH
    machine size 680 x 570 x 900H(mm)
    Vacuum Chamber 480 x 450 x 140H(mm)
    sealing bar length (1)420mm x 2
    (2)420mm x 1
    NW / GW 95kg / 115kg
    machine material #304 stainless
    Case Size(L*W*H) 780 x 650 x 1150(mm)
  • IC-612-24
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr (1HP)BUSCH
    machine size 670 x 570 x 900H(mm)
    Vacuum Chamber 480 x 450 x 240H(mm)
    sealing bar length 420mm x 2
    NW / GW 100kg / 120kg
    machine material #304 stainless
    Case Size(L*W*H) 780 x 650 x 1150(mm)(0.58CBM)
  • IC-612-50
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr (1HP)BUSCH
    machine size 720 x 650 x 910H(mm)
    Vacuum Chamber 530 x 530 x 140H(mm)
    sealing bar length 500mm x 2
    NW / GW 105kg
    machine material #304 stainless
    Case Size(L*W*H)
  • IC-712
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr(1HP)BUSCH
    machine size 680 x 930 x 920H(mm)
    Vacuum Chamber 470 x 780 x 140H(mm)
    sealing bar length (1)450mm x 2 / 650mm x 1
    (2)760mm x 2
    NW / GW 165kg / 195kg
    machine material #304 stainless
    Case Size(L*W*H) 780 x 1030 x 1170(mm)
  • IC-623
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 1.2kw
    Pump Capacity 40m3/hr(2HP)BUSCH
    machine size 760 x 930 x 1060H(mm)
    Vacuum Chamber 580 x 830 x 160H(mm)
    sealing bar length (1)800mm x 2
    (2)520mm x 2
    NW / GW 250kg / 290kg
    machine material #304 stainless
    Case Size(L*W*H) 800 x 1000 x 1310(mm)
  • IC-850
    Voltage 3HP / 220V or 380V
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 850 x 960 x 1100H(mm)
    Vacuum Chamber 730 x 890 x 220H(mm)
    sealing bar length (1)850mm x 2
    (2)650mm x 2
    NW / GW 280kg / 320kg
    machine material 304 stainless
    Case Size(L*W*H) 950 x 1060 x 1350(mm)
  • IC-850A(Pneumatic automatic swing lid)
    Voltage 3HP / 220V or 380V
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 850 x 960 x 1100H(mm)
    Vacuum Chamber 730 x 890 x 220H(mm)
    sealing bar length (1)850mm x 2
    (2)650mm x 2
    NW / GW 280kg / 320kg
    machine material 304 stainless
    Case Size(L*W*H) 950 x 1060 x 1350(mm)
  • IC-900
    Voltage 3HP / 220V
    Power 3kw
    Pump Capacity 100m3/hr (4HP)BUSCH
    machine size 790 x 1000 x 1060H(mm)
    Vacuum Chamber 670 x 930 x 210H(mm)
    sealing bar length 900mm x 2
    NW / GW 280kg / 320kg
    machine material #304 stainless
    Case Size(L*W*H) 960 x 1150 x 1340(mm)
  • IC-1620
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 2.2kw
    Pump Capacity 63m3/hr(3HP )BUSCH
    machine size 630 x 1620 x 920H(mm)
    Vacuum Chamber 470 x 1520 x 200H(mm)
    sealing bar length 450mm x 2
    NW / GW 320kg / 370kg
    machine material #304 stainless
    Case Size(L*W*H) 730 x 1720 x 1170(mm)
  • IC-624
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 2.2kw
    Pump Capacity 63m3/hr(3HP)BUSCH
    machine size 700 x 1800 x 1060H(mm)
    Vacuum Chamber 580 x 830 x 160H(mm) x 2
    sealing bar length 800mm x 4
    NW / GW 490kg / 550kg
    machine material #304 stainless
    Case Size(L*W*H) 800 x 1900 x 1310(mm)
  • IC-634
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 790 x 1820 x 1000H(mm)
    Vacuum Chamber 600 x 890 x 200H(mm)
    sealing bar length 720mm x 4
    NW / GW 490kg / 550kg
    machine material 304 stainless
    Case Size(L*W*H) 890 x 1920 x 1250(mm)
  • IC-635
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 810 x 1940 x 1000H(mm)
    Vacuum Chamber 640 x 980 x 200H(mm)
    sealing bar length 800mm x 4
    NW / GW 530kg / 570kg
    machine material #304 stainless
    Case Size(L*W*H) 910 x 2040 x 1250
  • AU2-850
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 5.6kw
    Pump Capacity 202m3/ hr (7.5HP)BUSCH
    machine size 900 x 2060 x 1120H(mm)
    Vacuum Chamber 720 x 1040 x 220H(mm)
    sealing bar length 850mm x 4
    NW / GW 620kg / 680kg
    machine material #304 stainless
    Case Size(L*W*H) 1000 x 2160 x 1450(mm)
  • IC-636
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 5.6kw
    Pump Capacity 202m3/hr(7.5HP)BUSCH
    machine size 1160 x 2100 x 1100H(mm)
    Vacuum Chamber 950 x 1060 x 300H(mm)
    sealing bar length 800mm x 4
    NW / GW 680kg / 756kg
    machine material #304 stainless
    Case Size(L*W*H) 1260 x 2200 x 1350 (mm)
  • IC-637
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 7.4kw
    Pump Capacity 302m3/hr(10HP)BUSCH
    machine size 1240 x 2400 x 1180H(mm)
    Vacuum Chamber 990 x 1180 x 300H(mm)
    sealing bar length 1000mm x 4
    NW / GW 730kg
    machine material #304 stainless
    Case Size(L*W*H)
  • IC-635A(Pneumatic automatic swing lid)
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 810 x 1940 x 1000H(mm)
    Vacuum Chamber 640 x 980 x 200H(mm)
    sealing bar length 800mm x 4
    NW / GW 530kg / 570kg
    machine material #304 stainless
    Case Size(L*W*H) 910 x 2040 x 1250(mm)
  • IC-636A(Pneumatic automatic swing lid)
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 5.6kw
    Pump Capacity 202m3/hr(7.5HP)BUSCH
    machine size 1160 x 2100 x 1100H(mm)
    Vacuum Chamber 950 x 1060 x 300H(mm)
    sealing bar length 800mm x 4
    NW / GW 680kg / 756kg
    machine material #304 stainless
    Case Size(L*W*H) 1260 x 2200 x 1350 (mm)
  • AU2-850A(Pneumatic automatic swing lid)
    Voltage 3HP / 220V or 380V 50Hz / 60Hz
    Power 5.6kw
    Pump Capacity 202m3/hr(7.5HP)BUSCH
    machine size 900 x 2060 x 1120H(mm)
    Vacuum Chamber 720 x 1040 x 220H(mm)
    sealing bar length 850mm x 4
    NW / GW 620kg / 680kg
    machine material #304 stainless
    Case Size(L*W*H) 1000 x 2160 x 1450(mm)
  • IC-641
    Voltage 220V or 380V / 50Hz / 60Hz
    Power 3kw or 5.6kw
    Pump Capacity 100m3 / hr or 202m3 / hr
    machine size 1960 x 1660 x 1310H(mm)
    distance between sealing bar 400mm
    Chamber height 100mm
    sealing bar length 1050mm
    NW 600kg
    machine material #304 stainless
  • IC-613
    Voltage 3HP / 220V
    Power 1.2kw
    Pump Capacity 40m3/hr(2HP)BUSCH
    machine size 810 x 850 x 910H(mm)
    Vacuum Chamber 570 x 800 x 140H(mm)
    sealing bar length (1)780mm x 2
    (2)540mm x 2
    NW / GW 220kg / 255kg
    machine material #304 stainless
    Case Size(L*W*H) 910 x 980 x 1140(mm)
  • TOUCH CONTROL PANEL:

    45 memories programs With package number indication With signal display of vacuum oil replacement User- friendly operation, independent displayed screen, easy to read, simple operation



    Options

    Gas flush device vacuum pressure setter sealing + bag cut ( two-stage heating) High pressure seal Filter for water / dust 8mm / 10mm wide sealing wire soft air
